For Mini 3 Battery 3850Mah Compatible Mini 3/Mini 3/4 Pro Series Intelligent Fli

Usage Instructions

Installation: Before inserting the battery, make sure your drone is completely powered off. Gently place the battery into the designated battery slot of the drone, ensuring a secure and proper connection.

Charging: Use the recommended charger to charge the battery. Follow the provided charging instructions carefully to avoid overcharging or damaging the battery. Do not leave the battery unattended during the charging process.

Operation: Once the battery is installed and charged, power on your drone and check the battery status indicator to confirm that it's working properly. During the flight, keep an eye on the battery level regularly to avoid running out of power mid-flight.

Storage: If you're not planning to use the battery for an extended period, store it in a cool, dry place at a partially charged state (around 40-60%). Avoid storing the battery in extreme temperatures or in direct sunlight to maintain its performance and longevity.
summary
The maximum endurance time is 45 minutes (Mini 4 Pro)/47 minutes (Mini 3 Pro)/51 minutes (Mini 3) *, providing ample framing and composition time, allowing you to bid farewell to endurance anxiety, fly to your heart's content, and return with a full load.
Connect the charging manager to a suitable power source using the provided power cable. Make sure the power source meets the specified voltage requirements.

Insert the batteries of high-end professional drones into the corresponding charging slots. Ensure that the batteries are properly inserted and make good electrical contact.

Observe the indicator lights on the charging manager. Different lights represent different charging statuses. Wait patiently for the batteries to be fully charged.

Once the batteries are fully charged, remove them from the charging slots in a timely manner. Do not leave the batteries in the slots for an extended period after they are fully charged to avoid potential battery damage.
reminder
*The battery life was measured in a controlled testing environment. The specific testing conditions are: altitude of 20 meters, no wind environment in the laboratory, flying forward at a constant speed of 21.6 kilometers per hour, switching to photography mode (no photography operation during the process), obstacle avoidance behavior set to off, and flying to 0% battery remaining. The results may vary to varying degrees in different external environments, usage methods, and firmware versions. Please refer to the actual experience for accuracy. When using long-range intelligent flight batteries, the weight of the aircraft may exceed 249 grams. Please check, confirm, and strictly comply with local laws and regulations before flying.
technical parameter
model: BWX162-3850-7.38
Capacity: 3850mAh
Nominal voltage: 7.38 volts
Charging limit voltage: 8.5 volts
Battery type: Li-ion
Energy: 28.4 watt hours
Charging time: 101 minutes (using PD 30W USB-C charger, charged through the aircraft body)
78 minutes (using PD 30W USB-C charger, charged through bidirectional charging manager)
Charging environment temperature: 5 to 40
Recommended charger: PD 30W USB-C charger or other charger that supports USB PD fast charging protocol
Compatible products
Mini 4 Pro
Mini 3 Pro
Mini 3
