HDMI-Compatible/MHL Digital Interface Separate Extract Audio I2S/Optic Fiber/Coaxial HDMI-Compatible To I2S/IIS Assembled

Package Included:

-Package A: B board(without shell)

-Package B: B board finished product(with shell)

-Package C:Support coaxial DOP board(with shell)

-Package D:Dual femtosecond top configuration(with shell)

Product Description:

It is used to extract digital audio signals from HDMI signals, supports I2S, optic fiber and coaxial outputs. It connects to decoders to improve sound quality. HDMI also supports MHL dual-mode input, and can also connect to mobile phones with MHL output, supporting 4K, 3D, and CEC functions. When connecting to most devices, no external power supply is needed. When there is lack of electricity of you player, you can use an external power supply (DC 5V).Input interface specification: 5.5 * 2.1.Note: Do not use a power supply exceeding 5V, otherwise it will be damaged.

Version Introduction:

- B board HDMI input, HDMI output, coaxial output, optical output, I2S output, HDMI OVER I2S output.

- B board finished productHDMI input, HDMI output, coaxial output, optical output, I2S output, HDMI OVER I2S output.

-Support coaxial DOP board: when DSD input, I2S port output DSD, coaxial output DOP64, the decoder needs to support DOP to use DOP

-Dual femtosecond top configuration: two large femtosecond crystal oscillators, ultra-low phase noise, ultra-low jitter, DSD can be up-converted to DSD256

Package Included:

-Package A: B board(without shell)

-Package B: B board finished product(with shell)

-Package C:Support coaxial DOP board(with shell)

-Package D:Dual femtosecond top configuration(with shell)

Note: The PCB color and capacitance of each batch are different, the actual product shall prevail, and we guarantee that the performance and the size of the circuit board will remain unchanged.
